如何把应用服务手动注册到Systemd

# 如何把应用服务注册到Systemd

郭群 于 2020年07月14日

systemctl_to_manage_systemd_services_and_units

# 一、引言

历史上，Linux 的启动一直采用init进程。 下面的命令用来启动服务。

$ sudo /etc/init.d/apache2 start
1

或者

$ service apache2 start
1

这种方法有两个缺点：

  • 一是启动时间长。init进程是串行启动，只有前一个进程启动完，才会启动下一个进程。
  • 二是启动脚本复杂。init进程只是执行启动脚本，不管其他事情。脚本需要自己处理各种情况，这往往使得脚本变得很长。

Systemd 就是为了解决这些问题而诞生的。它的设计目标是，为系统的启动和管理提供一套完整的解决方案。 根据 Linux 惯例，字母d是守护进程（daemon）的缩写。 Systemd 这个名字的含义，就是它要守护整个系统。

当前较新一些的Linux发行版，比如Ubuntu16以上、CentOS7以上、RedHat7以上的操作系统，其系统服务控制命令都开始使用Systemd，这种统一是件好事。

# 二、简介

Systemd 并不是一个命令，而是一组命令，涉及到系统管理的方方面面。 主要有如下一些命令：

  1. systemctl

systemctl是 Systemd 的主命令，用于管理系统

# 重启系统
$ sudo systemctl reboot

# 关闭系统，切断电源
$ sudo systemctl poweroff

# CPU停止工作
$ sudo systemctl halt

# 暂停系统
$ sudo systemctl suspend

# 让系统进入冬眠状态
$ sudo systemctl hibernate

# 让系统进入交互式休眠状态
$ sudo systemctl hybrid-sleep

# 启动进入救援状态（单用户状态）
$ sudo systemctl rescue
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
  1. systemd-analyze

systemd-analyze命令用于查看启动耗时

# 查看启动耗时
$ systemd-analyze

# 查看每个服务的启动耗时
$ systemd-analyze blame

# 显示瀑布状的启动过程流
$ systemd-analyze critical-chain

# 显示指定服务的启动流
$ systemd-analyze critical-chain atd.service
1
2
3
4
5
6
7
8
9
10
11
  1. hostnamectl

hostnamectl命令用于查看当前主机的信息

# 显示当前主机的信息
$ hostnamectl

# 设置主机名。
$ sudo hostnamectl set-hostname rhel7
1
2
3
4
5
  1. localectl

localectl命令用于查看本地化设置

# 查看本地化设置
$ localectl

# 设置本地化参数。
$ sudo localectl set-locale LANG=en_GB.utf8
$ sudo localectl set-keymap en_GB
1
2
3
4
5
6
  1. timedatectl

timedatectl命令用于查看当前时区设置

# 查看当前时区设置
$ timedatectl

# 显示所有可用的时区
$ timedatectl list-timezones

# 设置当前时区
$ sudo timedatectl set-timezone America/New_York
$ sudo timedatectl set-time YYYY-MM-DD
$ sudo timedatectl set-time HH:MM:SS
1
2
3
4
5
6
7
8
9
10
  1. loginctl

loginctl命令用于查看当前登录的用户

# 列出当前session
$ loginctl list-sessions

# 列出当前登录用户
$ loginctl list-users

# 列出显示指定用户的信息
$ loginctl show-user ruanyf
1
2
3
4
5
6
7
8

# 三、日常工作高频使用的的systemctl命令

用于启动和停止 Unit（主要是 service）

# 立即启动一个服务
$ sudo systemctl start apache.service

# 立即停止一个服务
$ sudo systemctl stop apache.service

# 重启一个服务
$ sudo systemctl restart apache.service

# 杀死一个服务的所有子进程
$ sudo systemctl kill apache.service

# 重新加载一个服务的配置文件
$ sudo systemctl reload apache.service

# 重载所有修改过的配置文件
$ sudo systemctl daemon-reload

# 显示某个 Unit 的所有底层参数
$ systemctl show httpd.service

# 显示某个 Unit 的指定属性的值
$ systemctl show -p CPUShares httpd.service

# 设置某个 Unit 的指定属性
$ sudo systemctl set-property httpd.service CPUShares=500
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26

# 四、配置示例

# （一）配置Prometheus

已知Prometheus安装在/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64目录

  1. 新增systemd配置文件：/etc/systemd/system/prometheus.service，将如下内容写入prometheus.service文件中
    [Unit]
Description=Prometheus
Wants=network-online.target
After=network-online.target

[Service]
User=root
Group=root
Type=simple
Restart=on-failure
ExecStart=/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/prometheus \
            --config.file=/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/prometheus.yml \
            --storage.tsdb.path=/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/data/ \
            --web.console.templates=/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/consoles \
            --web.console.libraries=/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/console_libraries \
            --web.enable-admin-api \
         --web.enable-lifecycle

[Install]
WantedBy=multi-user.target
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
  2. 重新加载配置：systemctl daemon-reload
  3. 将Prometheus设置为开机启动：systemctl enable prometheus
  4. 启动Prometheus：systemctl start prometheus
  5. 检查是否启动成功：
    [root@localhost prometheus]# systemctl status prometheus
● prometheus.service - Prometheus
   Loaded: loaded (/etc/systemd/system/prometheus.service; enabled; vendor preset: disabled)
   Active: active (running) since Tue 2020-07-14 10:12:56 CST; 24min ago
 Main PID: 28424 (prometheus)
   CGroup: /system.slice/prometheus.service
           └─28424 /store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/prometheus --config.file=/store_64G/opt/prometheus/prometheus-2.19.0.linux-amd64/prometheus.yml --storage.tsdb.path...

Jul 14 10:12:59 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:12:59.367Z caller=head.go:706 component=tsdb msg="WAL segment loaded" segment=18 maxSegment=21
Jul 14 10:12:59 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:12:59.447Z caller=head.go:706 component=tsdb msg="WAL segment loaded" segment=19 maxSegment=21
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.171Z caller=head.go:706 component=tsdb msg="WAL segment loaded" segment=20 maxSegment=21
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.172Z caller=head.go:706 component=tsdb msg="WAL segment loaded" segment=21 maxSegment=21
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.172Z caller=head.go:709 component=tsdb msg="WAL replay completed" duration=3.212636669s
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.249Z caller=main.go:694 fs_type=EXT4_SUPER_MAGIC
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.249Z caller=main.go:695 msg="TSDB started"
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.249Z caller=main.go:799 msg="Loading configuration file" filename=/store_64G/opt/prometh...metheus.yml
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.251Z caller=main.go:827 msg="Completed loading of configuration file" filename=/store_64...metheus.yml
Jul 14 10:13:00 localhost.localdomain prometheus[28424]: level=info ts=2020-07-14T02:13:00.251Z caller=main.go:646 msg="Server is ready to receive web requests."
Hint: Some lines were ellipsized, use -l to show in full.
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19

# （二）配置Grafana

已知Grafana安装在/store_64G/opt/grafana/grafana-7.0.3目录

  1. 新增systemd配置文件：/etc/systemd/system/grafana.service，将如下内容写入grafana.service文件中
    [Unit]
Description=Grafana
Wants=network-online.target
After=network-online.target

[Service]
User=root
Group=root
Type=simple
Restart=on-failure
ExecStart=/store_64G/opt/grafana/grafana-7.0.3/bin/grafana-server \
            -config=/store_64G/opt/grafana/grafana-7.0.3/conf/defaults.ini \
            -homepath=/store_64G/opt/grafana/grafana-7.0.3/

[Install]
WantedBy=multi-user.target
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
  2. 重新加载配置：systemctl daemon-reload
  3. 将Prometheus设置为开机启动：systemctl enable grafana
  4. 启动Prometheus：systemctl start grafana
  5. 检查是否启动成功：
    [root@localhost grafana]# systemctl status grafana
● grafana.service - Grafana
  Loaded: loaded (/etc/systemd/system/grafana.service; enabled; vendor preset: disabled)
  Active: active (running) since Tue 2020-07-14 10:45:11 CST; 5s ago
Main PID: 41206 (grafana-server)
  CGroup: /system.slice/grafana.service
          └─41206 /store_64G/opt/grafana/grafana-7.0.3/bin/grafana-server -config=/store_64G/opt/grafana/grafana-7.0.3/conf/defaults.ini -homepath=/store_64G/opt/grafana/grafana-7.0.3/

Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Path Data" logger=settings path=/store_64G/opt/grafana/grafana-7.0.3/data
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Path Logs" logger=settings path=/store_64G/opt/grafana/grafana-7.0.3/data/log
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Path Plugins" logger=settings path=/store_64G/opt/grafana/grafana-7.0.3/data/plugins
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Path Provisioning" logger=settings path=/store_64G/opt/grafana/grafana-7.0.3/...rovisioning
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="App mode production" logger=settings
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Connecting to DB" logger=sqlstore dbtype=sqlite3
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Starting DB migration" logger=migrator
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Starting plugin search" logger=plugins
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="Registering plugin" logger=plugins name="Direct Input"
Jul 14 10:45:11 localhost.localdomain grafana-server[41206]: t=2020-07-14T10:45:11+0800 lvl=info msg="HTTP Server Listen" logger=http.server address=[::]:3000 protocol=http subUrl= socket=
Hint: Some lines were ellipsized, use -l to show in full.
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19

# （三）配置Node-Exporter

已知node-exporter安装在/store_64G/opt/node_exporter/node_exporter-1.0.0.linux-amd64目录

  1. 新增systemd配置文件：/etc/systemd/system/node_exporter.service，将如下内容写入node_exporter.service文件中

    [Unit]
Description=Node Exporter
Wants=network-online.target
After=network-online.target

[Service]
User=root
Group=root
Type=simple
Restart=on-failure
ExecStart=/store_64G/opt/node_exporter/node_exporter-1.0.0.linux-amd64/node_exporter

[Install]
WantedBy=multi-user.target
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14

  2. 重新加载配置：systemctl daemon-reload

  3. 将Node-Exporter设置为开机启动：systemctl enable node_exporter

  4. 启动Node-Exporter：systemctl start node_exporter

  5. 检查是否启动成功：

    [root@localhost grafana]# systemctl status node_exporter
● node_exporter.service - Node Exporter
   Loaded: loaded (/etc/systemd/system/node_exporter.service; enabled; vendor preset: disabled)
   Active: active (running) since Tue 2020-07-14 11:22:26 CST; 7s ago
 Main PID: 55513 (node_exporter)
   CGroup: /system.slice/node_exporter.service
           └─55513 /store_64G/opt/node_exporter/node_exporter-1.0.0.linux-amd64/node_exporter

Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.720Z caller=node_exporter.go:112 collector=thermal_zone
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.720Z caller=node_exporter.go:112 collector=time
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.720Z caller=node_exporter.go:112 collector=timex
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.720Z caller=node_exporter.go:112 collector=udp_queues
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.720Z caller=node_exporter.go:112 collector=uname
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.720Z caller=node_exporter.go:112 collector=vmstat
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.721Z caller=node_exporter.go:112 collector=xfs
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.721Z caller=node_exporter.go:112 collector=zfs
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.721Z caller=node_exporter.go:191 msg="Listening on" address=:9100
Jul 14 11:22:26 localhost.localdomain node_exporter[55513]: level=info ts=2020-07-14T03:22:26.721Z caller=tls_config.go:170 msg="TLS is disabled and it cannot be enabled on the fl...http2=false
Hint: Some lines were ellipsized, use -l to show in full.
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19

参考资料：

《Systemd 入门教程：命令篇 - 阮一峰的网络日志》
